4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

4-Leafs Center Opening Elevator Landing Door Device 600-1200mm
4-Leafs Center Opening Elevator Landing Door Device 600-1200mm
4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Büyük resim :  4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Ürün ayrıntıları:
Place of Origin: China
Marka adı: SUNNY
Sertifika: CE,ISO9001
Model Number: SN-OCM-206
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1Set
Fiyat: $500~1200
Packaging Details: container
Delivery Time: 7~15 days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 5000pcs/month
İletişim

4-Leafs Center Opening Elevator Landing Door Device 600-1200mm

Açıklama
Name: 4-Leafs Center Opening Landing Door Device Product Name: 4-Leafs Center Opening Landing Door Device
JJ: 600~1200MM Used: Elevator Parts
System: Elevator control system Install: Car top installation
Transportation: Sea Delivery Applicable: Elevator Equipment
Model: 4-Leafs Center Opening Landing Door Device Type: 4-Leafs Center Opening Landing Door Device
Vurgulamak:

4-leafs elevator door operator

,

center opening elevator landing door

,

600-1200mm elevator door device

4-Leafs Center Opening Landing Door Device For Home Lifts (Common Spring Type)
Product Specifications
Attribute Value
Name 4-Leafs Center Opening Landing Door Device
Product Name 4-Leafs Center Opening Landing Door Device
JJ 600~1200MM
Used Elevator Parts
System Elevator control system
Install Car top installation
Transportation Sea Delivery
Applicable Elevator Equipment
Model 4-Leafs Center Opening Landing Door Device
Type 4-Leafs Center Opening Landing Door Device
Product Features
  • Self-closing type: Using common spring self-closing type. Common spring is located inside the upper side of landing door device
  • Using door jamb unlocking type. 70 sill is applicable, especially for home lifts
  • Multiple certificates: Door lock qualified by the NATIONAL ELEVATOR INSPECTION CENTER. Level of protection is IP2
  • Standard floor height ≥ HH+600, lowest floor height HH+400
  • Door lock voltages ≤ AC230V,≤ DC110V
Technical Specifications
JJ 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200
A1L 1050 1100 1150 1200 1250 1325 1400 1475 1550 1625 1700 1775 1850
A2L 145 145 145 145 145 157.5 170 182.5 195 207.5 220 232.5 245
A 225 225 225 225 225 237.5 250 262.5 275 287.5 300 312.5 325
B 75 62.5 50 37.5 25 25 25 25 25 25 25 25 25
C 377.5 390 402.5 415 427.5 452.5 477.5 502.5 527.5 552.5 577.5 602.5 627.5
Product Images
4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 0 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 1 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 2 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 3 4-Leafs Center Opening Elevator Landing Door Device 600-1200mm 4
Frequently Asked Questions
Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration considers not only wire rope and rated load, but also the size of the traction. The tensile strength of wire rope exceeds the weight of the lift, with a safety factor of at least four wire ropes to prevent simultaneous breakage.
Is it dangerous for power failure suddenly during the elevator running?
In case of power failure, the elevator will automatically stop due to electrical and mechanical safety devices. Elevator brakes will engage automatically. Power supply departments typically provide prior notice for planned outages.
Will us be hurt when it closed suddenly?
During closing, if the door contacts a person, it will automatically reopen without danger. The anti-pinch switch prevents closure when obstruction is detected, and closing force is carefully regulated.
How the elevator running?
Elevators operate via counterweight wire ropes through traction drive, moving vertically along guide rails.
Is the escalator installation complicated?
Our escalators feature integrated structures for precision and efficiency, making installation and commissioning simpler and more convenient.
Do you have any cerifications?
Yes, we hold ISO9001, CCC, and CE Certificates for our products.
